TransformerCart T48PD Perf. – USB-C
Key Technical Specifications:
✔ Charging Power: 48 × USB-C PD ports (5V/4A, 9V/2.1A, 12V/1.7A), max. 20W per port
✔ Compatibility: Tablets up to 11" (including thick protective cases), iOS/Android/Windows
✔ Cooling: 4 × fans (31 dB, 39 m³/h airflow), active & passive ventilation
✔ Security: Lockable enclosure, overcharge protection
✔ Mobility: 4 casters (2 lockable), 2 side carry handles, steering handle
✔ Power Supply: 100-240V, 50/60Hz, 960W total power output
✔ Dimensions: 680 × 480 × 1000 mm (L×W×H), Weight: 46 kg
Additional Features
Integrated LED charging status indicator per port
Labeling field for device identification
Cable management system for neat organization
Additional storage compartment for accessories
Includes 2m power cable (EU) and 2 keys
Technical Specifications - TransformerCart T24PD Perf. Plus – USB-C
General Specifications:
Model: TransformerCart T24PD Perf. Plus – USB-C 4.0
Type: Professional charging and transport cart
Maximum Device Capacity: 24 laptops/tablets
Maximum Device Size: Up to 15.6 inches (including protective cases)
----------------
Dimensions & Weight:
Overall Dimensions (L×W×H): 594 × 465 × 1086 mm (23.4 × 18.3 × 42.8 in)
Weight: 62 kg (136.7 lbs)
Compartment Dimensions (D×W×H): 396 × 23.3 × 268 mm (15.6 × 0.9 × 10.6 in)
-----------------------
Materials & Construction:
Housing Material: Steel sheet + aluminum alloy
Surface Material: Flame-retardant FR-ABS
Locking System: Integrated lock (2 keys included)
----------------------------------------------------
Charging Technology:
Number of Ports: 24 × USB-C 4.0
Power per Port: Up to 65W (Power Delivery)
Supported Voltages: 5V, 9V, 12V, 15V, 20V
Total Power Output: 2160W
Power Supply: 100-240V, 50/60Hz
Charging Indicator: LED per port (red = charging, green = fully charged)
-----------------------
Cooling & Safety:
Ventilation System: Active with 4 fans
Airflow: 39 m³/h
Noise Level: Max. 31 dBA
Overheat Protection: Automatic shutdown
Fire Protection: Flame-retardant materials
---------------------------------------
Transport & Handling:
Castors: 4 smooth-rolling castors (2 with locking mechanism)
Handles:
1 integrated push handle
2 retractable side handles
Mobility: Suitable for stair transport
----------------------------------------------------------------
Compatibility:
Supported OS: iOS, Android, Windows, macOS
Device Types:
Laptops up to 15.6"
Tablets up to 11"
Convertibles up to 14"
Protective Cases: Compatible with thick, standard and unknown cases
----------------------------------------
Connections & Accessories:
Power Connection: IEC socket
Included Accessories:
1 × 2m power cable (EU)
24 × 0.3m USB-C PD cables
2 × spare keys
User manual
-----------------------------------------
Certifications & Warranty:
Standards:
DIN EN 55022/55024 (EMC)
DIN EN 61140 (Safety)
DIN EN 62368-1 (Safety)
Certifications: CE, RoHS, REACH
Warranty: 1 year (extendable option)
